Copper Head Laps

Copper Head Laps

Boyar-Schultz makes the only copper head laps available. Copper extends the life span of the sleeve, thereby reducing downtime for lap changes. The design of our copper sleeves allows more lapping compound to be held and slowly distributed during any finishing process. They can be used on practically any material, hardened steel, carbide, chrome, ceramics, etc.

Available in both standard and expansion.

Category

Standard Copper Head Laps

Consists of steel arbor and replaceable copper sleeve. Extra sleeves are included with each lap as shown in product list.
 Part No. Size Part No. Size Six copper sleeves are included with each of the following: 104217 1/8" 104248 7/16" 104221 5/32" 104251 15/32" 104224 3/16" 104254 1/2" 104227 7/32" 104257 9/16" 104230 1/4" 104260 5/8" 104233 9/32" 104263 11/16" 104236 5/16" 104266 3/4" 104239 11/32" 104269 13/16" 104242 3/8" 104272 7/8" 104245 13/32" 104275 15/16"

Expansion Copper Head Laps

Consists of arbor, socket wrench and replaceable copper sleeve. (Arbor is made up of arbor expansion body, arbor shank, locking collar washer and socket-head screw.)
Extra sleeves are included.
Part No. Size Six copper sleeve are included. 104278 1"
