Roller Back Box Tools
Roller Back Box Tools
Now with straight line movement – interchangeable blade blocks – instant blade setting.
- Unique one-piece gage for setting all blades on center – instantly.
- Interchangeable blade blocks used on balance turning & roller back box tools – same blade block fits left or right hand balance or roller back tools.
- Same roll block can be used for left or right, upper or lower support on roller back tools – new screw adjustment on roll blocks.
- Interchangeable fine pitch adjusting screws for right hand, left hand, balance turning and roller back.
- Interchangeable retainers for right hand, left hand, balance turning and roller back.
We have eliminated the time-consuming trial and error required when you set other balance turning tools. One setting gauge is all you need to instantly center the blades.
All items are price on application.
| Model | Shank Diameter | Turning Length | RH & LH Capacity Diameter | RH Or LH Operation | Replaces These Old Tools | Setting Gage Used |
| 711-51-200 | 5/8” | * 1-1/4” | .090” to .340” .340” to .625” | Right Hand | 711-51-100 | 711-57-100 |
| 711-52-200 | 5/8” | * 1-1/4” | .090” to .340” .340” to .625” | Left Hand | 711-52-100 | 711-57-100 |
| 711-51-420 | 3/4″ | * 2” | .180” to .380” .380” to .625” | Right Hand | 711-51-320 | 711-57-122 |
| 711-51-422 | 1” | * 2-1/2” | .560” to .625” .625” to 1-1/2” | Right Hand | 711-51-322 | |
| 711-52-322 | 1” | * 2-1/2” | .560” to .625” .625” to 1-1/2” | Left Hand | 711-52-222 | |
| 711-53-222 | 1” | * 2-3/8” | .185” to .625” .625” to .750” | Right Hand | 711-53-122 | 711-57-100 |
| 711-54-222 | 1” | * 2-3/8” | .185” to .625 .625” to .750” | Left Hand | 711-54-122 | 711-57-100 |
- * Turned diameter will pass through shank bore.
- For diameters below .125”, use Roll Holders number 211-5139-1. See extended roll holders.
| INCHES | |||||||||||||
| TOOL NO. | A | B | C | D | E | F | G | J | M | N | P | Q | BLADES |
| 711-51-200 | .69 | 1.37 | 1.52 | .62 | 1.32 | .38 | 1.30 | .88 | .88 | .88 | .04 | .31 | 5/16 x 5/16 |
| 711-51-420 | .69 | 2.07 | 2.32 | .75 | 1.50 | .44 | 1.60 | 1.10 | 1.21 | 1.21 | .06 | .44 | 7/16 x 7/16 |
| 711-51-422 | 1.56 | 2.66 | 2.216 | 1.00 | 2.00 | .69 | 2.00 | 1.68 | 1.81 | 1.81 | .10 | .50 | 1/2 x 1/2 |
| 711-52-200 | .69 | 1.37 | 1.52 | .62 | 1.32 | .38 | 1.30 | .88 | .88 | .88 | .04 | .31 | 5/16 x 5/16 |
| 711-52-322 | 1.56 | 2.66 | 3.16 | 1.00 | 2.00 | .69 | 2.00 | 1.68 | 1.81 | 1.81 | .10 | .50 | 1/2 x 1/2 |
| 711-53-222 | .81 | 2.56 | 3.06 | 1.00 | 2.0 | .69 | 1.62 | 1.12 | 1.28 | 1.28 | .06 | .44 | 7/16 x 7/16 |
| 711-54-222 | .81 | 2.56 | 3.06 | 1.00 | 2.0 | .69 | 1.62 | 1.12 | 1.28 | 1.28 | .06 | .44 | 7/16 x 7/16 |
- Note: Turning length is unlimited when the workpiece will pass through the tool shank.
